Product Description
1. Continuous sucker rod production line
The continuous sucker rod production line is mainly composed of two parts: welding production line and heat treatment production line.
2. Main equipment of continuous sucker rod production line
In the production process, uncoiler, straightening machine, flash butt welding machine, power tractor, flaw detection machine, induction heating furnace, roll forming machine, shot blasting machine and so on are mainly used. The production line is highly integrated and easy to operate. The whole production process can be completed by 5-7 people. It can deal with the material of continuous sucker rod with diameter of 15mm-47mm. It can be applied to products of different specifications. Annual treatment capacity can reach 100000 meters.
3. Engineers design according to the factory layout, so I need to know the floor plan of the factory and workshop.
Product Details
1.The continuous sucker rod production line is mainly composed of two parts: welding production line and heat treatment production line.
1.1 Main Procedures of Welding Production Line
Open book
Straighten
Testing
welding
Flaw detection
Tow
Length measurement
Storage
1.2. Main Procedures of Heat Treatment Production Line
Welded raw materials
Induction heating furnace
Roller press
Quench
Induction heating furnace
tempering
Shot blasting anticorrosion
Testing
Storage
2.The product range of this production line
| Model | Size | Unit Mass | | Section(min) | | Max Diameter | | Min Diameter | |
| mm | lb/ft | kg/m | In2 | Mm2 | inch | mm | in | mm |
| CSR 7 | 27.00 | 3.01 | 4.49 | 0.89 | 572.00 | 1.43 | 35.60 | 0.75 | 18.90 |
| CSR 8 | 28.60 | 3.38 | 5.02 | 0.99 | 642.00 | 1.57 | 46.20 | 0.75 | 18.90 |
| CSR 2 | 19.00 | 1.50 | 2.24 | 0.44 | 285.00 | 0.87 | 22.10 | 0.60 | 15.20 |
| CSR 3 | 20.60 | 1.76 | 2.63 | 0.52 | 334.00 | 0.94 | 24.10 | 0.65 | 16.50 |
| CSR 4 | 22.20 | 2.04 | 3.05 | 0.60 | 388.00 | 1.01 | 25.50 | 0.70 | 17.80 |
| CSR 5 | 23.80 | 2.35 | 3.50 | 0.69 | 445.00 | 1.12 | 29.70 | 0.73 | 18.50 |
| CSR 6 | 25.40 | 2.67 | 3.98 | 0.79 | 507.00 | 1.26 | 32.30 | 0.74 | 18.80 |
| CGR 3 | 20.60 | 1.76 | 2.63 | 0.52 | 334.00 | 0.81 | 20.60 | 0.81 | 20.60 |
| CGR 4 | 22.20 | 2.04 | 3.05 | 0.60 | 388.00 | 0.87 | 22.20 | 0.87 | 22.20 |
| CGR 5 | 23.80 | 2.19 | 3.26 | 0.64 | 415.00 | 0.94 | 23.80 | 0.94 | 23.80 |
| CGR 6 | 25.40 | 2.67 | 3.98 | 0.79 | 507.00 | 1.00 | 25.40 | 1.00 | 25.40 |
| CGR 7 | 28.00 | 3.25 | 4.83 | 0.95 | 615.00 | 1.10 | 28.00 | 1.10 | 28.00 |
2.Continuous sucker rod storage
Round special storage shelves are needed at both ends of the production line. Five shelves can be stacked and stored before delivery, saving storage space and connecting shelves with special vehicles for easy transportation.
|
|
Continuous sucker rod production line for pumping unit ——one production line with only one sucker rod for an oil well Images
|
